Meet Our Best Selling Turning Centers

Lynx 2600SY

Horizontal Turning Center With Y-Axis

The biggest Lynx in the lineup, this particular cross roller linear guideway model maximizes its potential for long-term reliability, accuracy and the surface finishes you’ve been dreaming of. Mill-drill capability, and Y-axis with a full C-axis sub spindle greatly reduce the need for secondary operations, eliminating additional setup and handling costs.

  • 25 hp high torque digital AC spindle motor
  • Large 3.19″ bar capacity
  • High speed 3,500 rpm spindle
  • 12 station heavy duty servo controlled turret with 24 position indexing
  • Large 14.96″ maximum turning diameter
  • Widely spaced, high precision roller type linear motion guideways
  • 5,000 rpm, 7 hp, rotating tool spindle motor
  • Main spindle chuck: MH-210 10″ Samchully 3-jaw chuck. 254 mm (10″) diameter with 82 mm (3.23″) bore, 4.4 mm (.173″) jaw stroke – includes one set of soft jaws
  • Main spindle chuck actuator with chuck clamp / unclamp proximity switches: SD- 18582 hydraulic – 82 mm (3.23″) through hole – 30 mm (1.18″) stroke
  • Sub spindle chuck: MH-208 8″ Samchully 3-jaw chuck. 210 mm (8.26″) diameter with 66 mm (2.59″) bore, 3.7 mm (.145″) jaw stroke – includes one set of soft jaws
  • Programmable part catcher and part conveyor with bar feed interface standard
  • Automatic tool setter
  • Sub spindle part ejector with coolant flush
  • 65 psi multi-stage coolant pumps

PUMA GT 2600

2-Axis Horizontal Turning Center

Not every horizontal turning center is built to handle heavy applications. But with wide box way construction, faster rapid feed rates and the largest machining area in its class, this model handles them with ease. Its ability to handle heavy and interrupted cutting, yet deliver long term accuracy, and combination of ultra-rigid construction and advanced technology pushes the PUMA GT2600’s overall value above and beyond.

  • Rigid 30 degree one piece cast iron slant bed
  • Wide box way construction with Turcite-B anti-friction way surfaces
  • 12 station heavy duty servo controlled turret
  • 30 hp high speed – high torque digital AC spindle motor
  • Large 18.1″ maximum turning diameter
  • Large 3.19″ bar capacity
  • 25.9″ maximum turning length
  • Standard chuck specification: MH-210 10″ Samchully 3-jaw chuck. 254 mm (10″) diameter with 82 mm (3.23″) bore, 4.4 mm (.173″) jaw stroke – includes one set of soft jaws
  • Hydraulic chuck actuator: SD-18582 with 82 mm (3.23″) through hole
  • Programmable hydraulic tailstock (body clamp, drive pin and quill) – MT #5 live center
  • Tool setter
  • 65 psi multi-stage coolant pump
  • Separate coolant tank with way lube oil skimmer
  • Two year machine parts warranty, one year labor warranty.
  • Two year control warranty: Parts and labor
  • And more…
